eAMBIT103: 3" | 2-way | 25 WRMS

SPECS

SYSTEM

Effective Freq. Range

150Hz - 20kHz (-3dB)

Coverage angle / Dispersion

207°x207° (HxV)

Power handling

25 W RMS / 100 W Peak

Sensitivity

87 dB (1W/1m)

Maximum SPL

101 dB continuous / 107 dB Peak

Power options (Hi Z Multi-tap)

70/100V: 15W / 7,5W / 5W / 2,5W / 8Ω

Recommended amplifier power

50 W RMS

TRANSDUCERS

Ways

2 ways

Low frequency driver

3,5" woofer

High frequency driver

0,5 tweeter"

Nominal impedance

8Ω

PHYSICAL

Connection type

Spring loaded input terminals

Power type selector

Selector

Environmental

IP54 rated

Enclosure material

ABS

Mounting system

Cabinet

Operating temperature

Min: -10°C ; 14°F
Max: 40°C ; 104°F

Operating humidity

<85% HR

Storage temperature

Min: -10°C ; 14°F
Max: 40°C ; 104°F

Storage humidity

<90% HR

Included accessories

Includes on-wall hardware, safety sling, screws and wrench for fast installation

Finished colour

White (RAL 9016) or black (RAL 9005)

Dimensions

Without accessories: 120 x 120 x 118 mm / 4.72 x 4.72 x 4.65 in. (WxHxD)

Weight

1.275 kg / 2.81 lb

Pieces per box

Pair

Shipping dimensions

300 x 170 x 210 mm / 11.81 x 6.69 x 8.27 in. (WxHxD)

Shipping weight

1.45 kg / 3.2 lb

eAMBIT103: 3" | 2-way | 25 WRMS | discreet design

Applications
